Built-in Bluetooth makes it easy to monitor charging information, while the LCD display provides clear status information directly on the controller. Support for RS485 and RV-C also makes it suitable for more advanced installations and system integration.
The compact design takes up little space and is easy to integrate into different installations. With an operating temperature range from -30 to +65 °C, it is also suitable for changing outdoor conditions.
Advantages
- Efficient MPPT technology for optimised solar energy
- Supports 12 and 24 V battery systems
- Maximum charging current of 30 A
- Built-in Bluetooth for monitoring
- Clear LCD display
- RS485 and RV-C support
- Compatible with LiFePO4, AGM, SMF and GEL batteries
- Compact and lightweight design
- Suitable for motorhomes, caravans, boats and cabins
- Ideal for off-grid systems
Technical data
Voltage: 12/24 V
Maximum charging current: 30 A
Maximum panel voltage: 100 Voc
Maximum panel power with 12 V battery: 450 W
Maximum panel power with 24 V battery: 900 W
Battery types: LiFePO4, AGM, SMF, GEL
Operating temperature: -30 to +65 °C
Bluetooth: Built-in
IP rating: IP32
Connections/communication: RS485, RV-C
Dimensions: 162 x 108 x 62 mm
Weight: 0.7 kg
Approvals: RCM, FCC, CE, UKCA, RoHS, REACH
